Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage

Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage

Large Image :  Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage

Product Details:
Place of Origin: Guangdong, China
Brand Name: HUAIN
Model Number: HY-DA0404DA1
Contact Now
Detailed Product Description
Warranty: Other Power: Other
Voltage: 220V-240V Light Source Type: Other
Product Name: Dante Audio Output: 4/6/8output
Input: 4/6/8input Material: Matel,plastic
Type: Dante System Function: Digital Audio Processor Dante
Certificate: CE ROHS FCC CCC Style: Professional
Color: Black Channel: 2,4
Customized: Yes

Dante Digital audio media matrix by HUAIN adopts ADI share architecture, 40bit DSP processing chip.
we can provide 4 / 8 / 12 / 16 channel input and output lines, built-in USB interface, supports multiple occasions of local recording and broadcasting and remote conference, and supports dual central control of UDP and RS-232 / 485.
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 0
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 2
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 4
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 6
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 8
Product Function
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 10
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 12
Multiple control modes:
RS232 / network port control; Optional (8-key media matrix control panel, media matrix control panel, 10.1-inch Android wired induction screen) if necessary, please contact us for quotation!
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 14
Compatible with Windows / Android / ISO control interface and wireless WiFi control， 8 groups of GPIO universal purpose I / O digital signal control ports, which can be used as independent ADC.
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 16
Specification
model
4 × 4 Dante digital audio matrix
Audio input
4-way balanced input, Phoenix interface
Input quantization
96KHz/24bit
dynamic range
110dB
frequency response
20Hz—20KHz(±0.5dB)
Phantom Power
DC 48V
sampling rate
96KHz
Audio output
4-way balanced line level, Phoenix interface
DSP frequency
80 MHz
A / D dynamic range
114dB
Output impedance
102dB
Output quantization
48KHz/24bit
Minimum load impedance
600Ω
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 18
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 20
Company Profile
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 22
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 24
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 26
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 28
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 30
FAQ
1. who are we?
We are based in Guangdong, China, start from 2015,sell to Domestic Market(40.00%),Africa(13.00%),Mid East(8.00%),Southeast Asia(6.00%),North America(5.00%),Central America(5.00%),Northern Europe(5.00%),South Asia(5.00%),Eastern Asia(3.00%),Southern Europe(3.00%),South America(2.00%),Eastern Europe(2.00%),Western Europe(2.00%),Oceania(00.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Conference System/Conference System Equipments/Paperless Conference System/Sound Amplification System/Central Control System

4. why should you buy from us not from other suppliers?
Zhuhai Huain Electronic Technology Co.,Ltd is a professional in modern conferences products designer,a research and development Manufacturer.All the products were certified by CE,ROHS,FCC,3C,ISO,Patents according to their strict standards and regulations.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Portuguese
Custom Dante Digital Analog Audio Interface Dsp Poe Module Matrix Processor Processeur 8 in 8 Out 4 X 4 16x16 with Usb for Stage 32
