32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control

32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control

Large Image :  32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control

Product Details:
Place of Origin: Guangdong, China
Brand Name: HUAIN
Model Number: HY-D32A1
Contact Now
Detailed Product Description
Warranty: Other Power: Other
Voltage: 220V-240V Light Source Type: Other
Product Name: Dante Analog Conversion Interface Box Output: 32 Output
Input: 32 Input Material: Matel,plastic
Type: Dante System Function: Dante Analogue Converter
Certificate: CE ROHS FCC CCC Style: Professional
Color: Black Channel: 32
Customized: Yes

Products Description
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 0
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 2
Technical parameters: 1: Dante converter with 32-channel analog line input/output, compatible with Dante protocol. Support the construction of highly stable and flexible system 2: Each analog input supports independent 48V phantom power control 3：Each input supports independent feedback suppression function. 4: A master and a standby dual network port connection can be used to build a dual network with multiple redundant systems 5：Support USB and network connection PC debugging 6：Dante Controller can realize flexible routing configuration.
Specification
model
32 Dante digital audio matrix
Audio input
32-way balanced input, Phoenix interface
Input quantization
96KHz/24bit
dynamic range
110dB
frequency response
20Hz—20KHz(±0.5dB)
Phantom Power
DC 48V
sampling rate
96KHz
Audio output
4-way balanced line level, Phoenix interface
DSP frequency
80 MHz
A / D dynamic range
114dB
Output impedance
102dB
Output quantization
48KHz/24bit
Minimum load impedance
600Ω
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 4
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 6
Company Profile
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 8
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 10
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 12
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 14
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 16
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 18
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 20
FAQ
1. who are we?
We are based in Guangdong, China, start from 2015,sell to Domestic Market(40.00%),Africa(13.00%),Mid East(8.00%),Southeast Asia(6.00%),North America(5.00%),Central America(5.00%),Northern Europe(5.00%),South Asia(5.00%),Eastern Asia(3.00%),Southern Europe(3.00%),South America(2.00%),Eastern Europe(2.00%),Western Europe(2.00%),Oceania(00.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Conference System/Conference System Equipments/Paperless Conference System/Sound Amplification System/Central Control System

4. why should you buy from us not from other suppliers?
Zhuhai Huain Electronic Technology Co.,Ltd is a professional in modern conferences products designer,a research and development Manufacturer.All the products were certified by CE,ROHS,FCC,3C,ISO,Patents according to their strict standards and regulations.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Portuguese
32 Channel Dante Analog Switch Audio Interface Box with 48V Phantom Power Control 22
